ELECTRONIC HYGROSTAT SKR-3118

(SFTD-011)

ELECTRONIC HYGROSTAT SKR-3118

features

  • Compact Design
  • Set Temperatur
  • High Switching Capacity
  • Clip Fixing

Tamper-proof thermostat for regulating heaters and switching signal devices, combined with a hygrosat for controlling humidity and preventing condensation.

Principle of Operation

  • Tamper-proof (pre-set) thermostat/contact breaker (NC) for regulating heaters or switching signal devices when the temperature falls below the minimum value.
  • The contact opens when the temperature rises. The SR-3118 Hygrostat senses the relative humidity in an enclosure with electric/electronic components and turns on a heater at the set point, helping prevent the formation of condensation in the enclosure.

    Uses:

    • These are especially used for controlling fan filter, heater and heat exchanger, also could be monitoring the electric cabinet inner temperature when working as signal arouser.

    Important

    • 1. Makebimetal sensor as heat sensitivity set to feedback of heat
    • 2. Contact point scheme:single switchover contact point as instant switch component
    • 3. Voltage scope is wide any type could be used from 24V to 230V
    • 4. Time-saving connection,terminal block could be installed with screw from outside screw from outside
    • 5. Easy installation,could be installed to 35mm din rail vertically or horizontally according to EN50 022, it could be clipped to NS/35-ES cabinet profile with its accessory adapter.
